Description
Working Principle
- Based on the differential density of steam and liquid.
Features
- The valve body and bonnet are made of cast steel/forged steel.
- All internal parts are made of stainless steel, and the wear allowance has been fully considered in the design of movable parts, which improves the service life of the trap.
- Special flow channel design to achieve zero water hammer. System double guarantee no steam leakage and long service life.
- Patented flexible closing system and micron-level precision closing
- Built-in air vent valve to prevent steam lock.
- The independent filter makes the trap work in a clean environment.
- Choose different displacement curves according to the pressure.
- Back pressure rating≥95%
- A drain plug is designed at the bottom of the steam trap to drain intemal accumulated water after shutdown, preventing the float from being damaged by freezing.
