LOW TEMPERATURE BELLOWS GATE VALVE
LOW TEMPERATURE BELLOWS GATE VALVE Data Dimension

Low Temperature Bellows Gate Valve

  • Double seal design with bellows and packing makes the seal at the valve stem more secure.
  • The extended bonnet design the temperature of packing above 0 C,the packing and gasket meet ISO15848-1 Class A standards.
Get A Quote

Low Temperature Bellows Gate Valve

  • 2024 年 7 月 27 日

Description

Product Advantage

  • Double seal design with bellows and packing makes the seal at the valve stem more secure.
  • The extended bonnet design the temperature of packing above 0℃,the packing and gasket meet ISO15848-1 Class A standards.
  • Valve channel safety protection design to prevent abnormal pressure rise in the channel.
  • Oil ban and degreasing, UV detection, high cleanliness of the inner cavity.
  • Suitable for low temperature conditions, can be set according to customer requirements of low temperature isolation drip tray to prevent the valve stem packing freeze.

Specifications

  • Design standard:API602
  • Face to face dimension:ASME B16.10
  • Flange ends:ASME B16.5
  • Test & Inspection:API 598

Application

Suitable for polysilicon, Silane gas, Low temperature media, etc.

Advantages of VMV Bellows

  • The test items of bellows sealed valves meet the requirements of different working conditions
  • For the following general tests, VMV products have been tested in accordance with the specificat ions at the factory
  • Users can make special tests and other tests according to the actual working condions

Quality Control

  • VMV Standard bellows materials: SS304/SS316L
  • Special bellows materials:Inconel 625/Hastelloy 276/Monel allo y etc.
  • VMV can help customers choose suitable bellows for differen working condions.

Data Dimension Table

NPS 150LB 300LB 600LB
L W H≈ L W H≈ L W H≈
1/2＂ 108 Φ95 225 140 Φ95 225 165 Φ95 225
3/4＂ 117 Φ95 233 152 Φ95 233 190 Φ95 233
1 127 Φ117 268 165 Φ117 268 216 Φ117 268
1 1/4 140 Φ145 310 178 Φ145 310 229 Φ145 310
1 1/2 165 Φ145 330 190 Φ145 330 241 Φ145 330
2＂ 178 Φ200 515 216 Φ200 535 292 Φ200 565
2 1/2 191 Φ200 595 241 Φ200 610 330 Φ250 645
3＂ 203 Φ250 665 283 Φ250 690 356 Φ250 710
4＂ 229 Φ280 800 305 Φ300 820 432 Φ300 890
5＂ 254 Φ300 910 381 Φ300 940 508 Φ400 1020
6＂ 267 Φ300 1040 403 Φ350 1070 559 Φ450 1190
8＂ 292 Φ350 1310 419 Φ400 1360 660 Φ500 1490
10＂ 330 Φ400 1710 457 Φ450 1800 787 Φ600 1820
12＂ 356 Φ450 2030 502 Φ500 2180 838 Φ680 2210
14＂ 381 Φ500 2300 762 Φ550 2380 889 Φ600 2450
16＂ 406 Φ550 2580 838 Φ600 2650 991 Φ600 2800
