Quality Control
- The test items of bellows sealed valves meet the requirements of different working conditions
- For the following general tests, VMV products have been tested in accordance with the specificat ons at the factory
- Users can make special tests and other tests according to the actual working condions
Bellows Valve Check Items
| General Detecon | Inspecon Items | General Detecon |
| Material Inspecon | According To Relevant Material Standards | |
| Visual Inspecon | MSS SP-55,JB/T 7927-2014 | |
| Dimension Inspecon | Machining Drawing File | |
| Pressure Test | API598,EN12266 | |
| Air Tightness Test | API598,EN12266 | |
| Valve Seat Leakage Check | API598,EN12266 | |
| Funconal Check | API598,EN12266 | |
| Bellows Leakage Check | API598,EN12266 |
| Special Detecon lt | Test Items | Standard Specificaon |
| RT Radiography | ASME | |
| PT Liquid Penetraon Test | ASME | |
| UT Ultrasonic Inspecon | ASME | |
| Low Leakage Detecon | ISO15848 |
Common Subject Material Comparison Table
| ASTM Casng | DIN/EN Casng | ASTM Forging | JIS Casng |
| A216 WCB | 1.0619/GS-C25 | ASTM A105 | G5151 SCPH2 |
| A536 60-40-80 | JS1049/GGG40 | – | G5502 FCD400-15 |
| A352 LCB | 1.1131/G17Mn5 | A350 LF2 | G5152 SCPL1 |
| A217 WC6 | 1.7357/G17CrMo5-5 | A182 F11 | – |
| A217 WC9 | 1.7379/G17CrMo9-10 | A182 F22 | G5151 SCPH-32 |
| A351 CF8 | 1.4308/GX5CrNi19-10 | A182 F304 | G5151 SCS13A |
| A351 CF3 | 1.4309/GX2CrNi19-11 | A182 F304L | G5151 SCS19A |
| A351 CF8M | 1.4408/GX5CrNiMo19-11-2 | A182 F316 | G5151 SCS14A |
| A351 CF3M | 1.4409/GX2CrNiMo19-11-2 | A182 F316L | G5151 SCS16A |
| A351 CF8C | 1.4552/GX5CrNiNb19-11 | A182 F316LN | G5151 SCC21 |
| A351 CG8M | 1.4412/GX5CrNiMo19-11-3 | A182 F317 | – |
Bellow Material Comparison Table
| Material Comparison | GB | ASTM | DIN/EN |
| 06Cr19Ni10 | A240 304 | 1.4301 | |
| 022Cr19Ni10 | A240 304L | 1.4306 | |
| 06Cr17Ni12Mo2 | A240 316 | 1.4401 | |
| 022Cr17Ni12Mo2 | A240 316L | 1.4404 | |
| 316Ti | A240 316Ti | 1.4571 | |
| Gh625 | Inconel 625 | 2.4856 | |
| Ni68Cu28Fe | Monel 400 | 2.4360 | |
| 00Cr16Ni75Mo2Ti | Hastelloy C-276 | 2.4819 |
